Air Cooled Chiller 10HP Hot Selling Industrial Ice Water Brand New Air Cooled Water Chiller For Industrial Areas Requiring Cool Down

Our air cooled scroll chillers deliver precise, energy-efficient temperature control for critical industrial processes. Engineered with robust scroll compressor technology and requiring no external cooling tower, these compact units offer easy installation, low maintenance, and consistent performance in demanding environments. Ideal for plastics, laser cutting, medical equipment, food processing, and more.

Request Quote

Product Description

Specifications

Product Features

Product Video

More Details

Product Description

Air Cooled Chiller: Reliable Cooling • Zero Water • Minimal Space.
Simplified cooling for commercial and industrial applications

Key Advantages

✅ No Cooling Tower Needed
Eliminate water systems and complex plumbing

✅ Space-Saving Design
Install on rooftops or compact areas (40% smaller footprint)

✅ Lower Maintenance
No water treatment or condenser cleaning required

✅ Energy Efficient
IPLV ratings up to 6.0 with inverter technolog

Specifications

Model	LA001	LA002	LA003	LA005	LA006	LA008	LA010	LA012
Cooling capacity 50hz (kw)	2.98	5.49	9.3	15.5	18.3	21.5	27.8	35.1
Cooling capacity 50hz (kcal/h)	2,563	4,721	7,998	13,330	15,738	18,490	23,908	30,186
Cooling capacity 60hz (kw)	3.57	6.52	11.1	18.5	21.9	25.7	33.3	42
Cooling capacity 60hz (kcal/h)	3,070	5,607	9,546	15,910	18,834	22,102	28,638	36,120
Input power (kw)	1.38	2.15	2.65	4.47	6.3	6.55	8.65	11.05
Chilled fluid flow 50hz (m3/h)	0.51	0.94	1.6	2.67	3.14	3.7	4.8	6
Chilled fluid flow 60hz (m3/h)	0.61	1.12	1.92	3.18	3.76	4.4	5.72	7.2
Powe supply voltage	1ph-220v-50hz/60hz / (1ph-110v-50hz/60hz)		3ph-380v-50hz(200v/220v/415v 50hz/60hz)
Compressor Type	Hermetic ratating type		Hermetic scroll type
Compressor Start-up model	Sequential start
Compressor power(kw)	0.95	1.73	2.3	3.8	5.1	5.6	7.5	9.4
Refrigerant Type	R22(R407c/R410a/R134a)
Refrigerant Control mode	Capillary		Expansion valve
Refrigerant Filling amount	0.6	1.2	2	3.6	4.3	5.1	6.5	8.2
Evaporator Type	Water tank with coil		Shell and tube(Water tank with coil)
Evaporator Pipe (B)	PT1/2″		PT1″	PT1-1/2″				PT2″
Condenser Type	High efficient finned copper tube
Condenser Surface area/row(M2)	0.5/2R	0.62/3R	0.62/3R	0.62/4R	0.62/4R	1.16/3R	1.16/4R	1.92/3R
Cooling fan Type	Low noise axial flow(Low noise outer rotor fan)
Cooling fan Air volume(CMM)	17	35	65	110	126	150	195	220
Cooling fan power(kw)	0.18	0.21	0.25	0.37	0.42	0.55	0.55	0.75
Tank volume (L)	20	25	50	70	70	120	130	130
water pump power (kw)	0.37	0.37	0.37	0.75	0.75	0.75	1.1	1.1
Protective device	Compressor overheating, over current, high and low pressure, over temperature, flow switch, phase sequence, phase-missing, exhaust overheating, anti-freezing, etc.
Dimension L (mm)	550	600	930	1140	1140	1200	1300	1500
Dimension W (mm)	440	500	520	560	560	740	780	780
DimensionH (mm)	750	850	975	1040	1040	1370	1530	1600
Weight (kg)	72	100	150	170	190	370	400	450

Product Features

Scroll Compressor Reliability: Durable, quiet operation with fewer moving parts for extended lifespan and reduced maintenance.

Energy Efficient: Optimized design minimizes power consumption and operational costs.

Simplified Installation & Operation: Air-cooled design eliminates the need for complex water piping or cooling towers.

Precise Temperature Control: Maintains tight temperature stability (±1°C typical) for process integrity.

Robust Construction: Built for reliable 24/7 operation in industrial settings.

Compact Footprint: Space-saving design for flexible facility integration.

Advanced Controls: User-friendly interface for monitoring and adjustment (Optional: mention specific features like remote monitoring if standard).
