1. High Efficiency and Energy Saving; Excellent Part-Load Performance
|
|||||||||||||
|
Utilizing two-stage compression or variable frequency drive (VFD) technology, the unit achieves a Coefficient of Performance (COP) exceeding 6.1 and meets the national Grade 1 standard for Integrated Part-Load Value (IPLV). Stepless capacity modulation is available across a 15%–100% load range; since the unit operates under part-load conditions for approximately 99% of its runtime with minimal efficiency loss, it saves 20%–30% in electricity compared to traditional centrifugal chillers.
|
|||||||||||||
| 2. Stable, Reliable Operation and Long Service Life | |||||||||||||
|
The centrifugal compressor features few moving parts, resulting in an average service life of 80,000 hours. The two-stage compression design offers a much wider operating range than single-stage models, making it less prone to surging. Certain models utilize oil-free magnetic bearing technology for frictionless operation, extending the service life to over 25 years; the absence of an oil system eliminates the need for oil changes and related maintenance.
|
|||||||||||||
| 3. Low Noise and Low Vibration | |||||||||||||
|
Operating noise for magnetic-bearing centrifugal chillers can be as low as 78 dB, making them ideal for noise-sensitive environments such as schools, concert halls, and museums. The oil-free design eliminates mechanical friction noise associated with traditional bearings and significantly reduces vibration levels.
|
|||||||||||||
| 4. Compact Structure; Easy Installation and Maintenance | |||||||||||||
|
The positive-pressure design reduces the unit’s footprint by approximately 35% compared to negative-pressure models, saving valuable mechanical room space. Units are factory-charged with refrigerant and lubricant, requiring only water and power connections for immediate startup. The evaporator is designed for easy cleaning without major overhauls; routine maintenance is limited to cleaning the water system.
|
|||||||||||||
| 5. Eco-friendly Refrigerants; Green and Low-Carbon | |||||||||||||
|
Uses environmentally friendly refrigerants such as R134a (ODP=0) or R1234ze. Magnetic-bearing models employ oil-free systems, significantly reducing refrigerant charge requirements and effectively lower carbon emissions.
|
| Centrifugal Chiller – Fixed-Speed – High-Efficiency Single-Unit / Model | TKC500 | TKC600 | TKC700 | TKC800 | TKC900 | TKC1000 | TKC1400 | ||||||
| Cooling capacity (kW) | 1758 | 2150 | 2450 | 2820 | 3150 | 3880 | 4950 | ||||||
| Cooling capacity (kcal/h) | 1,511,880 | 1,849,000 | 2,107,000 | 2,425,200 | 2,709,000 | 3,336,800 | 4,257,000 | ||||||
| Input power (kW) | 275 | 325 | 385 | 435 | 500 | 550 | 758 | ||||||
| Full-load COP kW/kW | 6.37 | 6.49 | 6.39 | 6.47 | 6.33 | 6.34 | 6.48 | ||||||
| Full-load COP kW/RT | 0.55 | 0.54 | 0.55 | 0.54 | 0.56 | 0.55 | 0.54 | ||||||
| Condenser : | Condenser : | ||||||||||||
| Water flow (m³/h) | 350 | 420 | 490 | 558 | 630 | 700 | 976 | ||||||
| Water pressure drop (kPa) | 45 | 45 | 45 | 50 | 50 | 50 | 60 | ||||||
| Inlet and outlet pipe connections (DN) | 250 | 250 | 250 | 300 | 300 | 350 | 350 | ||||||
| Refrigeration oil charge (L) | 575 | 590 | 805 | 920 | 1035 | 1150 | 1610 | ||||||
| Evaporator: | Evaporator: | ||||||||||||
| Water flow (m³/h) | 302 | 364 | 420 | 485 | 545 | 606 | 846 | ||||||
| Water pressure drop (kPa) | 60 | 60 | 66 | 72 | 72 | 80 | 85 | ||||||
| Inlet and outlet pipe connections (DN) | 250 | 250 | 250 | 300 | 300 | 350 | 350 | ||||||
| InStallation Size | Installation Size: | ||||||||||||
| D (mm) | 3235 | 3435 | 3435 | 4570 | 4570 | 4780 | 4780 | ||||||
| E (mm) | 2000 | 2000 | 2000 | 2000 | 2000 | 2000 | 2300 | ||||||
| Shipping weight (kg) | 9300 | 9800 | 11400 | 12100 | 12800 | 13500 | 18500 | ||||||
| Operating weight (kg) | 10250 | 11400 | 12550 | 13400 | 14300 | 15100 | 20500 | ||||||
| Dimension W (mm) | 1100 | 1200 | 1200 | 1300 | 1350 | 1400 | 1400 | ||||||
| Overall dimensions | Overall dimensions: | ||||||||||||
| Length (mm) | 4360 | 4560 | 3440 | 3440 | 3440 | 3440 | 3440 | ||||||
| width (mm) | 2200 | 2250 | 2250 | 2420 | 2420 | 2420 | 2800 | ||||||
| height (mm) | 2400 | 2450 | 2450 | 2850 | 2850 | 2850 | 2950 | ||||||
| Applicable refrigerant | R134a / R1234ze | ||||||||||||
| Operating Conditions |
Evaporator: Inlet water temperature 12°C, outlet water temperature 7°C;
Condenser: Inlet water temperature 30°C, outlet water temperature 35°C; Condenser and evaporator connections are flanged. |
||||||||||||
