Our air cooled screw chillers deliver robust, large-scale cooling for demanding industrial processes. Combining the proven reliability and efficiency of screw compressor technology with the convenience of air-cooled operation, these units offer powerful performance without the complexity of cooling towers or water systems. Ideal for facilities requiring heavy-duty, continuous cooling with minimal infrastructure.

Request Quote

Product Description

Specifications

Product Features

Product Video

More Details

Product Description

Air Cooled Screw Chiller: Heavy-Duty Cooling • Extreme Environments • Maximum ROI

Industrial-grade reliability for large commercial and process applications

Key Advantages

✅ High-Capacity Cooling

100-800 RT range | Single-unit solutions

✅ 30% Energy Savings

IPLV up to 6.3 with VFD-driven screws

✅ Harsh Environment Ready

Operates at -15°C to 50°C ambient

✅20-Year Lifespan

Bi-rotor screws with <0.5% maintenance cost

Specifications

Model			LAS040	LAS050	LAS060	LAS080	LAS100	LAS120	LAS150
Cooling capacity		kw	120	149	189	237	300	367	398
Cooling capacity		kcal/h	103,200	128,140	162,540	203,820	258,000	315,620	342,280
Input power		kw	38.7	48.2	58	71	92.9	116.3	121.4
Chilled fluid flow		m3/h	20	26	32	35	50	60	76
Powe supply voltage			3ph-380v-50hz/60hz（200v 220v 415v)
Compressor	Type		Semi-hermetic screw type
	Starting method		0,33,66,100		0,25,50,75,100
	power(kw)		34.3	43.8	53.6	66.5	84.1	107.5	112.6
Refrigerant	Type		R22(R407c/R134a)
	Control mode		Thermostatic expansion valve
	Filling amount(kg)		21.0	26.0	31.0	35.0	49.0	58.0	78.0
Evaporator	Type		Shell and tube
Evaporator	Pipe	B	PT3″			PT4″		PT5″
Condenser	Type		High-efficient air cooled inner threaded copper-tubing aluminum fin type
Cooling fan	Type		Low noise outer rotor fan
	Air volume(CMM)		940	940	940	940	1790	1790	1790
	Power(kw)		2.2*2	2.2*2	1.1*4	1.5*4	1.5*6	2.2*6	2.2*8
Protective device			Compressor overheating, over current, high and low pressure, over temperature, flow switch, phase sequence, phase-missing, exhaust overheating, anti-freezing, etc.
Dimension	L	mm	2300	2500	2200	2200	3050	4400	4500
	W	mm	1110	1200	2100	2100	2100	2100	2100
	H	mm	2110	2200	2000	2300	2100	2100	2100
Weight		kg	1330	1680	1850	1960	3320	3420	3460

Product Features

High Capacity & Efficiency: Screw compressors provide superior cooling power and excellent part-load efficiency for large-scale applications.

Robust & Reliable: Heavy-duty screw compressors ensure stable 24/7 operation with minimal vibration, designed for long service life in harsh industrial environments.

Simplified Installation & Operation: Air-cooled design eliminates the need for cooling towers, condenser water pumps, piping, and water treatment – reducing installation costs and complexity.

Reduced Maintenance: Fewer external components (vs. water-cooled) and durable screw technology lower lifetime maintenance requirements and costs.

Space-Efficient Design: Integrated air-cooled condenser maximizes cooling capacity within a compact footprint.

Ideal for Water-Scarce/Dry Climates: No water consumption for heat rejection.

Advanced Control & Monitoring: Intelligent microprocessors optimize performance, provide system diagnostics, and enable remote monitoring (Optional: Specify features like IoT).

Built for Harsh Conditions: Corrosion-resistant coatings and robust components ensure performance in demanding industrial settings.
