Low Temperature Glycol Chillers: Sub-Zero Precision • -40°C Capability • Antifreeze Protection • Process-Grade Reliability
Engineered for freezing, dehumidification, and viscous fluid cooling
Key Advantages
✅Ultra-Low Temperatures
-40°C to -10°C range with glycol/brine solutions
✅ Burst Protection
Prevents pipe freezing in sub-ambient environments
✅±0.5°C Stability
PID-controlled precision for sensitive processes
✅High-Viscosity Ready
Positive displacement pumps for glycol mixtures
✅30% Energy Savings
Economized compression with subcooling recovery
| Model | LWSL120 | LWSL130 | LWSL150 | LWSL160 | LWSL180 | LWSL080 | LWSL100 | ||
| Cooling capacity(kw) -10℃ | 221 | 238.5 | 283.6 | 299.5 | 331.4 | 155.1 | 201.5 | ||
| Cooling capacity(kw) -20℃ | 149.4 | 161.2 | 191.5 | 202.4 | 223.8 | 104.7 | 136.5 | ||
| Cooling capacity(kw) -30℃ | 94 | 101.3 | 120.5 | 127.2 | 140.7 | 65.9 | 85.7 | ||
| Input power（kw） | 69.5 | 76.6 | 91.7 | 93.8 | 105.5 | 53.8 | 68 | ||
| Freezing fluid flow （m3/h） | 60 | 65 | 75 | 80 | 90 | 41 | 47.2 | ||
| Cooling fluid flow （m3/h） | 72 | 78 | 90 | 96 | 108 | 82 | 49.2 | ||
| Powe supply voltage | 3ph-380v-50hz/60hz (200v 220v 415v) | ||||||||
| Compressor Type | Semi-closed | ||||||||
| Compressor Number | 1 | 2 | |||||||
| Compressor Starting method | Y-▲ | ||||||||
| Compressor Capacity adjustment | 0-100% | ||||||||
| Compressor power(kw) | 69.5 | 76.6 | 91.7 | 93.8 | 105.5 | 26.9*2 | 34*2 | ||
| Frozen oil Type | HBR-03(HBR-05) | ||||||||
| Frozen oil Filling amount(L) | 16 | 15 | 18 | 20 | 23 | 7*2 | 7*2 | ||
| Refrigerant Type | R22(R407c) | ||||||||
| Refrigerant Control mode | Temperature-sensitive external pressure equalization expansion valve | ||||||||
| Refrigerant Filling amount(kg) | 60 | 65 | 75 | 80 | 90 | 21*2 | 26*2 | ||
| Evapotator Type | Shell tube type (material stainless steel 304/316/alloy copper) | ||||||||
| Evaporator Pipe(B) | PT5″ | PT6″ | PT4″ | ||||||
| Condenser Type | Shell and tube | ||||||||
| Condenser Pipe(B) | pt5″ | pt6″ | PT4″ | ||||||
| Protective device | High and low voltage switch, antifreeze protection, soluble plug/safety valve, overload protection device, coil overheat protector, temperature automatic protection switch, etc. | ||||||||
| Dimension L (mm) | 3200 | 3200 | 3700 | 3700 | 3700 | 2800 | 3300 | ||
| Dimension W (mm) | 1100 | 1160 | 1200 | 1250 | 1250 | 940 | 940 | ||
| Dimension H(mm) | 1500 | 1550 | 1550 | 1600 | 1650 | 1620 | 1650 | ||
| Weight(Kg) | 2250 | 2400 | 2500 | 2600 | 2650 | 1930 | 2200 | ||
Sub-Zero Cooling Range: Designed for reliable operation down to -40°F / -40°C (typical, specify your range) using glycol/water mix.
Freeze Protection: Glycol solution prevents freezing in pipes, coils, and process equipment, ensuring safe operation in extreme cold.
Precision Temperature Control: Maintains tight stability (±0.5°C) essential for sensitive processes.
Corrosion-Resistant Construction: Critical components (evaporator, reservoir, piping) use stainless steel or protected materials to withstand glycol solutions.
Industrial Durability: Built for 24/7 operation in harsh environments with high-quality compressors (screw or scroll) and heavy-duty components.
Secondary Cooling Loop: Safely isolates the chiller’s refrigerant circuit from the process, protecting sensitive equipment.
High Glycol Concentration Capability: Engineered to handle the viscosity and thermal properties of high-% glycol solutions.
Advanced Controls & Alarms: Programmable controllers, data logging, and comprehensive safety alarms for critical process monitoring.
Flexible Configuration: Available as air-cooled or water-cooled models to suit facility infrastructure.
